Frontier V4 – Crossover RWD Electric Wheelchair

Frontier V4 – Crossover RWD Electric Wheelchair

Magic Mobility

Tailor your chair

  • Select a Colour:

    Lucent Lime

  • Select Wheels:

    Crossover

  • Select Tyre & Rim Colours:

    Black/Silver

  • *Premium colours (including hot pink, ultra violet, lucent lime, burnt orange, sunrise yellow, silver streak, forest green, army green and blaze blue) will incur an additional cost. Please note that premium colours may vary in the EU. The Frontier V4 range of powerchairs is no longer available in the USA.

    Disclaimer: Actual colours and designs may vary slightly over time due to differences in product finishes. Please refer to physical examples for accurate representation.

Cross over to more outdoor fun

A powered wheelchair for those who know what they want. The thinking person’s chair, the V4 Crossover Rear Wheel Drive (RWD) is designed for those who are asking themselves the question about getting around the street or off-road, as well as indoors. Swap your Crossover tyres to either Off-road or Urban tyres to ensure you get the best powered wheelchair for your lifestyle.

  • Drive mode: Rear wheel drive
  • Motors: 2 x 800W, Gear in line
  • Environments: Everyday off-road, urban and indoors
  • Excellent stability

  • Great battery life and distance

  • Exceptionally smooth ride due to all wheel suspension

  • Tight indoor accessibility with a simple tyre change

  • 004-done Created with Sketch.

    Proudly Australian made

    Since 1994, we have been designing, engineering and manufacturing highly robust, all terrain powerchairs in Melbourne, Australia so that active users can experience a world that’s not flat.

  • Splash resistant (not waterproof)

    Please remember, the wheelchair has electric motors and must not be driven through water, into rivers, creeks, or the sea. Magic Mobility wheelchairs meet Australian Standards 3696 and ISO7176.

Brochures and manuals

Magic Mobility produces world-class electric wheelchairs. Download your Frontier V4 RWD product brochure or Owner’s Manual here.

Technical specifications

FeaturesSpecifications
*Length of base995mm / 39" (*legrest choice and seating size may increase chair length/width)
*Width of base700mm / 27.5"
Floor to top of seat pan height435mm / 17"
Turning circle (radius) of base525mm / 20.5"
User Weight limit182kg / 401lb fixed frame, 155kg / 341lbs with lift &/or tilt
Top speed10kph (6.2mph)
Top speed at full seat elevation5kph / 3.1mph
Motors2 x 68Nm Torque, 800W, Gear in Line
Motor IP Rating 54 (splash resistant but not waterproof)The wheelchair has electric motors and must not be driven through water, into rivers, creeks, or the sea
Wheels - Crossover14" (5.30/4.50/6) black or grey (pneumatic only)
CastorsØ220mm (280/250-4), black or grey (solid or pneumatic)
BatteriesGel
Controller Penny & Giles with LCD display (R-net) or LED option
Legrest optionsCentre post, manual elevating, power/manual elevating swingaway, centre mount power elevating
Backrest and seatAdjustable seat pan (12” deep to 24” wide) to fit MPS / Rehab or aftermarket seating options
Tie down pointsCrash test compliant
