Frontier V4 – Urban RWD Electric Wheelchair

Magic Mobility

Tailor your chair

  • Select a Colour:

    Forest Green

  • Select Wheels:

    Urban

  • Select Tyre & Rim Colours:

    Black/Silver

Adventure Gained. Nothing Lost.

A powered wheelchair for those who know what they want. The thinking person’s chair, the V4 Rear Wheel Drive (RWD) is designed for those who are asking themselves the question about getting around the street or off-road, as well as indoors. Swap your Urban tyres to either Off-road or Crossover tyres to ensure you get the best powered wheelchair for your lifestyle.

  • Drive mode: Rear wheel drive
  • Motors: 68 Nm Torque, 2 x 800W, Gear in line
  • Environments: Urban outdoors and roomy indoors
  • Excellent stability

  • Great battery life and distance

  • Exceptionally smooth ride due to all wheel suspension

  • tire

    Upgrade to off-road capability with a simple tyre change

  • 004-done Created with Sketch.

    Proudly Australian made

    Since 1994, we have been designing, engineering and manufacturing highly robust, all terrain powerchairs in Melbourne, Australia so that active users can experience a world that’s not flat.

  • Splash resistant (not waterproof)

    Please remember, the wheelchair has electric motors and must not be driven through water, into rivers, creeks, or the sea. Magic Mobility wheelchairs meet Australian Standards 3696 and ISO7176.

Brochures and manuals

Magic Mobility produces world-class electric wheelchairs. Download your Frontier V4 RWD product brochure or Owner’s Manual here.

Technical specifications

FeaturesSpecifications
*Length of base930mm (*legrest choice and seating size may increase chair length/width)
*Width of base640mm (710mm with off-road wheels, 700mm with crossover wheels)
Floor to top of seat pan height435mm
Turning circle (radius) of base520mm
Weight limit182kg (400lbs), 155kg (340lbs) with lift or tilt
Top speed10kph (6.2mph)
Motors68Nm Torque, 800W, Gear in Line
Motor IP Rating 54 (splash resistant but not waterproof)The wheelchair has electric motors and must not be driven through water, into rivers, creeks, or the sea
Wheels - Urban14"x3'' black or grey (solid or pneumatic)
Wheels - Crossover14" (5.30/4.50/6) black or grey (pneumatic only)
Wheels - Off-road14" black (note silver rims not available in the USA)
CastorsØ220mm (280/250-4), black or grey (solid or pneumatic)
BatteriesGel
Controller Penny & Giles with LCD display (R-net) or LED option
Legrest optionsCentre post, manual elevating, power/manual elevating swingaway, centre mount power elevating
Backrest and seatAdjustable seat pan (12” deep to 24” wide) to fit MPS / Rehab or aftermarket seating options
Tie down pointsCrash test compliant
