Frontier V4 – Off-road FWD Electric Wheelchair

Magic Mobility

Tailor your chair

  • Select a Colour:

    Space Blue

  • Select Wheels:

    Off-road

  • Select Tyre & Rim Colours:

    Black/Silver

  • *Premium colours (including hot pink, ultra violet, lucent lime, burnt orange, sunrise yellow, silver streak, forest green, army green and blaze blue) will incur an additional cost. Please note that premium colours may vary in the EU and USA. Silver rims are not available in the USA on the offroad wheels.

    Disclaimer – Actual colours and designs may vary slightly over time due to differences in product finishes.  Please refer to physical examples for accurate representation.

For the road less travelled

A powered wheelchair for those who know what they want. The V4 Front Wheel Drive (FWD) offers a great solution to some of life’s most tricky corners. The thinking person’s chair, it’s designed for those who are asking themselves the question about getting around their homes with ease, using desks and tables or driving frequently. Choose off-road, crossover or hybrid wheels to ensure you get the best power wheelchair for your lifestyle.

  • Drive mode: Front wheel drive
  • Motors: 68 Nm Torque, 2 x 800W, Gear in Line
  • Environments: Everyday off-road
  • tire

    Compact with great off-road capability and stability

  • Powerful kerb climbing

  • Exceptionally smooth ride due to all wheel suspension

  • Great battery life and distance

  • 004-done Created with Sketch.

    Proudly Australian made

    Since 1994, we have been designing, engineering and manufacturing highly robust, all terrain powerchairs in Melbourne, Australia so that active users can experience a world that’s not flat

  • Splash resistant (not waterproof)

    Please remember, the wheelchair has electric motors and must not be driven through water, into rivers, creeks, or the sea. Magic Mobility wheelchairs meet Australian Standards 3696 and ISO7176.

Brochures and manuals

Magic Mobility produces world-class electric wheelchairs. Download your Frontier V4 FWD product brochure or Owner’s Manual here.

Technical specifications

FeaturesSpecifications
*Length of base995mm (*legrest choice and seating size may increase chair length/width)
*Width of base710mm (700mm with Crossover wheels, 640mm with Hybrid wheels)
Floor to top of seat pan height435mm
Turning circle (radius) of base520mm
Weight limit182kg (400lbs), 155kg (340lbs) with lift and/or tilt
Top speed10kph (6.2mph)
Motors68Nm Torque, 800W, Gear in Line
Motor IP Rating 54 (splash resistant but not waterproof)The wheelchair has electric motors and must not be driven through water, into rivers, creeks, or the sea
Wheels - Off-road14" black (note silver rims not available in the USA)
Wheels - Crossover14"(5.30/4.50/6) black or grey (pneumatic only)
Wheels - Hybrid14"x3" black or grey (Solid or pneumatic)
Castors Ø220mm (2.80/2.50-4), black or grey (solid or pneumatic)
BatteriesGel
ControllerPenny & Giles with LCD display (R-net) or LED option
Legrest optionsCentre post, manual elevating, power/manual elevating swingaway, centre mount power elevating
Backrest and seatAdjustable seat pan (12” deep to 24” wide) to fit MPS / Rehab or aftermarket seating options
Tie down pointsCrash test compliant
